SWx 900cw

NAVIGATION



COMBO MFD
9" WiFi chartplotter + CHIRP echosounder / fishfinder
with SEIWA Romeo software.


MADE IN ITALY


1270.00 € PLUS VAT



PRODUCT CODE: P3CR200WSE

MAIN FEATURES



MAIN FEATURES


SWx 900cw

Practical Hybrid Interface

The best of both approaches



The SWx series maximizes the combined benefits of a touch screen with the reliability of an ergonomic keypad


  • The rotary knob provides fast and precise control in every condition

  • The touch screen optimizes experience in map exploration and route building



SEIWA CHIRP technology

Higher resolution, less power, less noise


SEIWA SWx combo displays come with a CHIRP sonar to  offer  a high resolution view of targets for an efficient and sustainable fishing.

CHIRP stands for Compressed High-Intensity Radiated Pulse and is a game-changing  technology that has been used by the military, now finally available for professional and recreational sonar.

SEIWA CHIRP sonar transmits a longer pulse than traditional sonar, putting more energy into the water column  achieving:

  • HD resolution and target definition

  • Greater ability to pull targets from the background noise

  • Improved bottom tracking at higher speeds

  • Improved bottom tracking at deeper depths

SOFTWARE




SOFTWARE


ROMEO, the brain of SEIWA navigation systems



ROMEO software is what makes your marine electronics easy to use,
integrating data from different devices with the cartographic info.

Powerful and flexible, ROMEO is the result of SEIWA's deep knowledge
of both charting systems and marine instruments, gained in more than three decades of activity.

SEIWA ROMEO is constantly improved by our software development team
and our graphic user interface experts, also thanks to our customers' feedback.


Learn more

Configure your desired view

Everything under control


Personalize your display configuration: map, fish finder, radar, compass bar, data boxes, or split pages to have everything under control.

Full Map


Explore the Map

Explore your chart database with information on map objects

Full fishfinder


Full echosounder - fishfinder page

The CHIRP fishfinder technology eliminates surface clutter and water column noise, for hi-fi visibility.

Seiwa Romeo Instruments


Instruments  and Situational Widget

Connect to compatible sensors such as weather stations and gyrocompasse to view:  3D road, rate of turn, rudder, timer, temperature, roll, pitch, compass, speed, and depht graph.

Seiwa Romeo Radar page


Radar page / overlay
Transform your chartplotter into an integrated radar display for visual situational awareness, fully integrated with charts, AIS and other features.

Engine page


Engine Monitor
Display engine parameters and performance when connected to a compatible NMEA 2000 engine through CAN bus.

Split Page


Split page
Combine the 5 pages (map, fishfinder, radar, instruments, engine) in split pages creating 10 possible combinations to monitor everything

Fishing Ranges

Advanced map option for easier fishing



You can select on your SEIWA charplotter a fishing range: when you know the fish are suspended over certain depths, highlight the range so you can quickly identify more places to check out!


*Function available with NAVIONICS charts.


Learn more



Advanced data management

Tracks, routes and marks



  • The chartplotter interface is optimized for an easy, fast and accurate management of your data.

  • Create marks/events, tracks, routes, waypoints and boundaries and store them in the plotter database.

  • The advanced tracks management allows you to transform any track in a route.

  • You can manage up to 30,000 marks with a new set of colors and icons.

Radar Integration

Improved visual situational awareness


Transform your chartplotter into an integrated radar display for visual situational awareness, fully integrated with charts, AIS and other features.



Learn more

APPS



APPS


Exploit the full potential of your connected SEIWA plotter



Mirror Control

Duplicate your navigation plotter


Situational awareness is key onboard. It is very helpful to have multiple navigation displays while you move around your boat to keep everything under control, but it can be very expensive.

You can mirror your connected SEIWA navigation system on any mobile device through the MIRROR CONTROL  APP available for free for IOS and Android.

MIRROR CONTROL


Get extra displays
for free!

Learn more








Captain Cloud

Never lose your tracks and marks again


Syncronize your data with Captain Cloud and manage routes, tracks and marks from any connected device, keep them safe and private! Build your favorite routes easily at home, and find them ready on board!


*For SWx series and EXPLORER 23 WIFI version

Learn more

MAPS




MAPS


The best electronics charts for SEIWA systems


MAPS


Choose your favourite charts!


SEIWA navigation systems give you a wide choice of maps.

You can choose C-MAP 4D ®, C-MAP Max ®, Navionics+ ®, and Navionics Platinum+ ® maps.








Learn more




ACCESSORIES


ACCESSORIES

NMEA2000 + NMEA 0183 + WiFi



Build a complete, reliable and yet flexible system!

All the SWx series chartplotters are extremely versatile as they come with two NMEA0183 serial ports and one NMEA2000 port to connect any compatible device such as AIS, autopilot, engine, etc.

m8 smart gps receiver



M8 Smart GPS receiver

Waterproof Satellite Differential GPS Receiver
Learn more

Autopilot AP05



Autopilot SW AP05

The intelligent autopilot system for both power and sail 6m – 40m

Learn more

Radar Antenna MDS-12



Radar Antenna MDS-12

Transforms your chartplotter into an integrated radar display for visual situational awareness.

Learn more

GPS Vector Compass



GPS Vector Compass

Compact GPS Positioning and Heading Smart Antenna
Learn more

SI-TEX MDA1 AIS



SI-TEX MDA1
Metadata AIS Transceiver

High performance, plug-and-play AIS transceiver featuring Rmax™ Class B engine.

Learn more

Si-Tex MDA-2 Metadata Dual Channel AIS Receiver



SI-TEX MDA2
Metadata Dual Channel AIS Receiver

Dual Channel, plug-and-play AIS Receiver featuring Rmax™ AIS technology.

Learn more

SI-TEX MDA3 Metadata AIS Antenna Splitter



SI-TEX MDA3
Metadata AIS Antenna Splitter

Allows for the full use of VHF communications and AIS send/receive with a single antenna.
 Learn more

Sitex MDA-5AIS Class B/SO Transceiver/Splitter



SI-TEX MDA5
Class B/SO AIS Transceiver / Splitter

New 5 Watt AIS with built in Antenna Splitter
Learn more

help

 Need help in finding the right solution for you ?


Contact us

SPECIFICATIONS



SPECIFICATIONS

Hardware specifications SWx 900 cw

SWx 900cw Hardware Specifications
Display size: 9”  touchscreen
Display resolution: 800 x 480
Display brightness: 1100 nits
Weight: 1160 g
Maximum power 25W
Supply voltage 10-35 Vdc
Waterproof IPX6
Operating temperature -10°C / +60°C
Storage temperature -20°C / +80°C
Mounting options Bracket, surface, flush mount
Built-in GPS receiver 10 Hz GPS/GLONASS
External GPS connector
Built-in CHIRP Fish Finder
Tranducer connector
NMEA 2000
NMEA 0183 2x Rx/Tx on power cable 2
Micro SD memory slot
WiFi connectivity
Remote control receiver





SWx 900w Dimensions



A  278 mm (10.9 in)

B 154 mm (6.06 in)

C  174 mm (6.8 in)

D  64 mm (2.5 in)

E  32.6 mm (1.2 in)







INSTALLATION



INSTALLATION

Panel installation and connection scheme

MANUALS & DOWNLOADS



MANUALS & DOWNLOADS

User Manual swx900w

Installation Guide SWx 900w

Software Update SWx 900w
